DOMESTIC - STEEL RETAINERS

Model Engine /Part Nº	Val.Stem size	Diam.(A)	Out Step Diam.(B)	Inn Step Diam.(C)	References
RETAINERS “7 DEG.”
E10012	11/32	1.365	1.060	.735	Double Spring (Use with Ferrea Lock # K10067)
E10014	5/16-11/32	1.125	.886	.655	Double Spring
E10015	3/8	1.365	1.080	.735	Double Spring
